Wall Light RD007
Wall Light RD007
| Material | Aluminium |
| Surface | Polishing, wiredrawing, passivation, tinting |
| PowerMode | External, constant current/voltage |
| Installation | Embedded installation of buried lamp |
| Weight | |
| Control | On/o ff |
| Approvals | CE,RoHS,IP |
| Ambient temp. | -20°C ~+45°C |
| Average life | 50,000Hrs |
| Accessories |
RD007 Wall Light
Power(w) Input |
Luminous Flux (lm) |
Color(k) | Color Index PowerMode | Wiring |
Cable |
Beam (°) |
Model No. | ||
2 |
24VDC | 80 | C,W,N | 80 | Constant voltage | Parallel | 1.1M 2X0.75mm2 | 120 | RD007-1D |
| 4.5 | 24VDC | 200 | C,W,N | 80 | Constant voltage | Parallel | 1.1M 2X0.75mm2 | 120 | RD007-2D |
2 |
24VDC | 80 | C,W,N | 80 | Constant voltage | Parallel | 1.1M 2X0.75mm2 | 120 | RD007SQ-1D |
4.5 |
24VDC | 200 | C,W,N | 80 | Constant voltage | Parallel | 1.1M 2X0.75mm2 | 120 | RD007SQ-2D |
2 |
500mA | 80 | C,W,N | 80 | Constant current | Series | 1.1M 2X0.75mm2 | 120 | RD007-1 |
| 4.5 | 350mA | 200 | C,W,N | 80 | Constant current | Series | 1.1M 2X0.75mm2 | 120 | RD007-2 |
2 |
500mA | 80 | C,W,N | 80 | Constant current | Series | 1.1M 2X0.75mm2 | 120 | RD007SQ-1 |
| 4.5 | 350mA | 200 | C,W,N | 80 | Constant current | Series |
1.1M 2X0.75mm2 | 120 | RD007SQ-2 |
C-6000K/W-3000K/N-4000K/R-Red /G-Green/B-Blue/A-Amber;
Drive power supply to be provided separately page256/257
Product lists V
RD007 120DU
