LED Linear Strip Lights 2FT 4FT 8FT

LED Linear Strip Lights 2FT 4FT 8FT

Specification

• Manufacturer： Halcon Lighting
• Fixture Type：LED Linear Strip lighting fixture
• Lead Time: Ships in 1-2 weeks
• Qualifications: DLC Standard/DLC Premium, ETL/CETL List
• Voltage: Universal voltage 120-277V
• CCT Adjustable: 3000K/3500K/4000K/5000K
• Dimmable: 0-10V dimming standard
• Size: 2ft, 4ft, 8ft
• Operating Temperature: -4°F to 122°F (-20°C to 50°C), excluding EM models


Controls Features
  • Daylight Sensor
  • Occupancy Sensor
  • Integral Sensor Receptacle
  • High-end Trim
  • Bluetooth

• Model: HG-L205B
• Warranty: 5 years
• Wattage Adjustable: 15 to 25Watts / 20 to 40Watts / 55 to 65Watts / 50 to 80Watts
• CRI(Color rendering index):>80
• Lumen output: 3250 lm-8450 lm
• Light efficiency: 130 LP/W
• Aluminum body structure available in White finish
• Mounting: Surface mount, Pendant/Rod mount (accessories sold separately)

Accessories

SENSOR control, Emergency kits, suspension kits.

Design and Installation

Faster installation and cleanup

Available Switchable Color and Adjustable Lumen Technology.

Specification


HG-L205B-252F HG-L205B-404F HG-L205B-658F HG-L205B-858F
Size 605x60x82mm 1175x60x82mm 2327x60x82mm 2327x60x82mm
Nominal Wattage 15/20/25W 20/25/40W 55/60/65W 50/65/80W
InputVoltage AC 120-277V, 120-347V AC 120-277V, 120-347V AC 120-277V, 120-347V AC 120-277V, 120-347V
Lumen Delivered 3250 lm 5200 lm 8450 lm 8450 lm
Nominal Efficacy 130 lm/w 130 lm/w 130 lm/w 130 lm/w
CCT 3000K/3500K/4000K/5000K 3000K/3500K/4000K/5000K 3000K/3500K/4000K/5000K 3000K/3500K/4000K/5000K
CRI >80 >80 >80 >80
Power Factor >0.9 >0.9 >0.9 >0.9
Dimming 0-10V 0-10V 0-10V 0-10V
Operating Temperature -4˚F to 122˚F (-20˚ C to 50˚C ), except EM models. For EM model: 50˚F to 104˚F (10˚C to 40˚C ) -4˚F to 122˚F (-20˚ C to 50˚C ), except EM models. For EM model: 50˚F to 104˚F (10˚C to 40˚C ) -4˚F to 122˚F (-20˚ C to 50˚C ), except EM models. For EM model: 50˚F to 104˚F (10˚C to 40˚C ) -4˚F to 122˚F (-20˚ C to 50˚C ), except EM models. For EM model: 50˚F to 104˚F (10˚C to 40˚C )
Warranty 5 Years 5 Years 5 Years 5 Years
