LED Linear Linkable Light Strip Diffuser 2ft 4ft 8ft (5400 Lumen To 11475 Lumen) CCT 3000K-5000K And Watts Selectable 0-10V Dimmable Surface And Pendant Mount ETL & DLC Listed
LED Linear Linkable Light Strip Diffuser 2ft 4ft 8ft (5400 Lumen To 11475 Lumen) CCT 3000K-5000K And Watts Selectable 0-10V Dimmable Surface And Pendant Mount ETL & DLC Listed
Overview
Use Cases
Use Cases
Comparison Chart
Comparison Chart
Video
Use Cases
Office Unit Specification
| HG-L205C-252F | HG-L205C-404F | HG-L205C-658F | HG-L205C-858F | |
| Size | 609x75x83mm | 1200x75x83mm | 2438x75x83mm | 2438x75x83mm |
| Nominal Wattage | 15/20/25W | 20/25/40W | 55/60/65W | 55/60/65W |
| InputVoltage | AC 120-277V, 120-347V | AC 120-277V, 120-347V | AC 120-277V, 120-347V | AC 120-277V, 120-347V |
| Lumen Delivered | 3250 lm | 5200 lm | 8450 lm | 8450 lm |
| Nominal Efficacy | 130 lm/w | 130 lm/w | 130 lm/w | 130 lm/w |
| CCT | 3000K/3500K/4000K/5000K | 3000K/3500K/4000K/5000K | 3000K/3500K/4000K/5000K | 3000K/3500K/4000K/5000K |
| CRI | >80 | >80 | >80 | >80 |
| Power Factor | >0.9 | >0.9 | >0.9 | >0.9 |
| Dimming | 0-10V | 0-10V | 0-10V | 0-10V |
| Operating Temperature | -4˚F to 122˚F (-20˚ C to 50˚C ), except EM models. For EM model: 50˚F to 104˚F (10˚C to 40˚C ) | -4˚F to 122˚F (-20˚ C to 50˚C ), except EM models. For EM model: 50˚F to 104˚F (10˚C to 40˚C ) | -4˚F to 122˚F (-20˚ C to 50˚C ), except EM models. For EM model: 50˚F to 104˚F (10˚C to 40˚C ) | -4˚F to 122˚F (-20˚ C to 50˚C ), except EM models. For EM model: 50˚F to 104˚F (10˚C to 40˚C ) |
| Warranty | 5 Years | 5 Years | 5 Years | 5 Years |
